Voltas 12K-H4

Max. DC Input Power: 18,000W

PV Input Voltage: 650V (160V – 800V)

MPPT Voltage Range: 200V – 700V

Start-up Voltage: 160V

Rated AC Output Power: 12,000W

Protection Degree: IP65

Warranty: 5 Years

The Voltas 12K-H4 is a 12kW three-phase hybrid solar inverter in Pakistan, engineered for high performance and reliability in large homes with three-phase supply, offices, factories and commercial buildings. This hybrid solar inverter combines solar input, battery storage and UPS back-up output in one unit, so it works with the grid and keeps essential loads running during load shedding. It is a versatile choice for users looking to optimize their energy consumption.

Key Features:

  • Battery Input: Compatible with lead-acid or Li-ion batteries, with a 40V to 60V voltage range. This is a low-voltage battery inverter, so it is not designed for high-voltage (HV) battery stacks.
  • Max. Charge and Discharge Current: 250A for both, ensuring efficient energy management.
  • Charging Strategy: A 3-stage charging curve with equalization, self-adaption to the BMS for Li-ion batteries (CAN / RS485), and an optional external temperature sensor for enhanced performance.
  • Three-Phase Output: 12,000W rated AC output and UPS power (13,200W maximum) at 380/400Vac, with a peak power of 2 times the rated power for 10 seconds off-grid.

With a maximum DC input power of 18,000W, a PV input voltage of 650V (160V to 800V), an MPPT range of 200V to 700V and 2 MPPT trackers (2 + 1 strings), the inverter handles large solar arrays, with a start-up voltage of 160V. It reaches a maximum efficiency of 97.90% and a 99.90% MPPT efficiency. Protection includes PV input lightning protection, anti-islanding, reverse polarity protection, insulation resistor detection, residual current monitoring, output over-current and short-circuit protection and DC Type II / AC Type III surge protection, with PV ARC fault detection available as an option. With an IP65 rating, smart cooling, wall-mounted installation (44kg) and a 5-year warranty, the Voltas 12K-H4 ensures durability and reliable operation in various environments.

Frequently Asked Questions

Why is the Voltas 12K-H4 a powerful solar energy inverter?
The Voltas 12K-H4 delivers 12kW output power with up to 18kW of solar input capacity, making it a good fit for large homes, commercial buildings and small industrial solar systems. It helps maximize solar energy production and reduce electricity costs.

What is the price of the Voltas 12K-H4 Three-Phase Hybrid Inverter in Pakistan?
The price depends on installation requirements, warranty coverage and supplier availability. Contact Maxpower for the latest price and quotation.

Does the Voltas 12K-H4 support solar panels and battery backup?
Yes, the inverter accepts up to 18kW of PV input and works with both lithium-ion and lead-acid batteries (40V to 60V, up to 250A charge / discharge). This allows you to store excess solar energy and use back-up power during load shedding.

Is the Voltas 12K-H4 suitable for commercial solar energy projects?
Yes, its three-phase output (380/400Vac) makes it suitable for factories, offices, warehouses and commercial buildings that need three-phase power with hybrid energy management.

How many MPPT trackers does the Voltas 12K-H4 have?
It has 2 MPPT trackers (2 + 1 strings) with an MPPT range of 200V to 700V, which lets you connect panels in separate strings and track their maximum power point independently.

Can the Voltas 12K-H4 be used for net metering in Pakistan?
It is a grid-connected hybrid inverter and can be used in net metering setups. Please confirm the current approval requirements with your distribution company (DISCO) before installation.

What warranty does the Voltas 12K-H4 come with?
The Voltas 12K-H4 comes with a 5-year warranty.

Why should customers choose Maxpower for solar energy solutions?
Maxpower provides hybrid inverter solutions, battery-compatible systems and project support for residential and commercial users in Pakistan. The Voltas 12K-H4 is designed to deliver efficient solar energy performance with IP65 protection and a 5-year warranty.

Technical Specifications

Voltas 12KW/14KW datasheet
