Voltas 6KTLM-G4 Single Phase Ongrid Inverter

The Voltas 6KTLM-G4 Single Phase On-Grid Inverter is an excellent solution for residential solar energy systems. It is designed to optimize energy consumption and efficiency. With its compact and reliable design, this inverter is perfect for homeowners looking to harness solar power effectively.

The Voltas 6KTLM-G4 features a maximum input voltage of 600 V and a start-up input voltage of 40 V, allowing for quick system activation and efficient energy harvesting. Its MPPT voltage range is between 80 and 580 V, enabling the inverter to adapt seamlessly to varying solar conditions. With 2 MPPTs (Maximum Power Point Trackers), the inverter optimally manages power distribution to maximize energy production throughout the day.

Key Specifications:

• Rated Output Power: 6 kW
• Max Output Apparent Power: 6 KVA
• Rated AC Voltage: 220/230/240, L+N+PE
• AC Voltage Range: 180-300 V (adjustable)
• Max Output Current: 26 A
• Max Efficiency: 98.6%
• European Efficiency: 98.1%

Safety and reliability are:

• Key aspects of the Voltas 6KTLM-G4which features.
• Featuring ground fault monitoring.
• Output overvoltage protection.
• Anti-islanding protection.
• Integrated AFCI.

The inverter is rated IP66 (Protection Degree), providing superior protection against dust and water ingress, making it suitable for outdoor installations in various environments.

This inverter operates efficiently within a wide temperature range of -25 to +60°C, ensuring consistent performance even in challenging conditions.
