Voltas 25KTLX-G4 Three Phase Ongrid Inverter
- High PV input current, up to 18A
- LOW PV start-up voltage, generates power earlier
- Support Bluetooth communication, easier to set and monitor inverter parameters
- High converter efficiency
- IP66 protection degree
- 3 MPPTs, install more panels in different directions
- ARC fault detection optional
- Built-In Zero Export Function
- Built-In Load Monitoring Function
The Voltas 25KTLX-G4 is a high-capacity three-phase on-grid inverter tailored for large-scale energy systems. A rated output power of 25kW ensures consistent commercial and industrial application performance. Its maximum input voltage of 1,100V and wide MPPT range of 100-1,080V enable optimal solar energy utilization.
Equipped with three MPPT trackers and a maximum input current of 44A per MPPT, this inverter delivers precise energy management and supports a grid frequency range of 45-65Hz. The maximum efficiency of 98.6% ensures excellent energy conversion, while advanced safety features such as anti-islanding protection and DC reverse polarity protection ensure reliable operation.
Built with an IP66 ingress protection rating, the Voltas 25KTLX-G4 is designed for durability in challenging environments. Its transformerless design, external fan cooling, and support for surge arresters ensure smooth operation even in demanding conditions. Ideal for modern energy systems, this inverter is a leader in efficiency and reliability.
Technical Specifications
