Voltas 15KTLX-G4 Three Phase Ongrid Inverter

The Voltas 15KTLX-G4 Three-Phase on-Grid Inverter is designed for efficient and reliable solar energy management in commercial and industrial settings. With a hardy build and advanced technology, this inverter maximizes solar investment.

This inverter boasts a max input voltage of 1,100 V and a start-up input voltage of just 50 V, ensuring quick and efficient operation. Its MPPT voltage range of 100-1,080 V allows optimal energy extraction under varying sunlight conditions. Featuring 3 MPPTs (Maximum Power Point Trackers), the Voltas inverter effectively manages power distribution, enhancing energy output.

Key Specifications:

• Rated Output Power: 15 kW
• Max Output Apparent Power: 15 KVA
• Rated AC Voltage: 220/380, 230/400 V
• AC Voltage Range: 277-460 V (adjustable)
• Max Output Current: 217 A
• Max Efficiency: 98.6%
• European Efficiency: 98.3%

Safety is paramount with integrated features such as ground fault monitoring, output over-voltage protection, anti-islanding protection, and integrated AFCI. The inverter’s IP66 (Protection Degree) ensures it is resistant to dust and water, making it suitable for outdoor installation.

The Voltas 15KTLX-G4 operates efficiently in a temperature range from -25°C to +60°C, with an external fan-cooling system for optimal performance. With a transformerless topology, this inverter reduces space requirements and enhances efficiency.
