MP 220W Solar Panel
February 27, 2025MP 280W Solar Panel
Nominal Output (Pmpp): 280W
Open Circuit Voltage (Voc): 26.0V
Short Circuit Current (Isc): 12.03A
Voltage at Pmax (Vmpp): 24.5V
Current at Pmax (Impp): 11.2A
Cell Type: Mono-Crystalline Silicon (36 cells)
Maximum System Voltage: 1000VDC
The Maxpower MXM280Bi-36 is a 280W mono-crystalline solar panel for solar power systems in Pakistan, suited to homes, shops, farms and small commercial installations. It has 36 mono-crystalline silicon cells in a compact anodized aluminum frame with 3.2mm pattern front glass. See the full solar panel range for other options.
It has a nominal output of 280W, an open circuit voltage (Voc) of 26.0V, a short circuit current (Isc) of 12.03A, a voltage at Pmax (Vmpp) of 24.5V and a current at Pmax (Impp) of 11.2A. The maximum system voltage is 1000VDC. The temperature coefficient is -0.34%/°C for Pmax, -0.27%/°C for Voc and 0.04%/°C for Isc. All data is at STC (Standard Test Conditions).
The panel measures 1505 x 678 x 30 mm and weighs 11kg. It has a 1000mm output cable (1 x 2.5mm²) and an IP65 junction box (TUV & UL). It works from -40°C to +85°C and can handle a maximum surface load of 5,400 Pa on the front and 2,400 Pa on the rear. Browse Maxpower’s hybrid solar inverters to find an inverter that matches your panel string.
Frequently Asked Questions
What is the MXM280Bi-36 solar panel used for?
The MXM280Bi-36 is used to generate electricity from sunlight in solar power systems for homes, shops, farms and small commercial setups in Pakistan. It is connected to a compatible solar inverter or charge controller.
What are the power and electrical ratings of the MXM280Bi-36?
It has a nominal output of 280W, Voc of 26.0V, Isc of 12.03A, Vmpp of 24.5V and Impp of 11.2A at STC. The maximum system voltage is 1000VDC, and the Pmax tolerance is 0 to +3W.
What is the price of the MXM280Bi-36 solar panel in Pakistan?
The price depends on the current market rate and the quantity you need. Contact Maxpower for the latest price and quotation.
What is the size and weight of the MXM280Bi-36?
It measures 1505 x 678 x 30 mm and weighs 11kg. It has a 36-cell mono-crystalline design with an anodized aluminum frame and 3.2mm pattern front glass.
What temperature and load limits does the MXM280Bi-36 have?
The operating temperature is -40°C to +85°C, and the nominal operating cell temperature (NOCT) is 45±2°C. The maximum surface load is 5,400 Pa on the front and 2,400 Pa on the rear.
What are the temperature coefficients of the MXM280Bi-36?
The temperature coefficient of Pmax is -0.34%/°C, of Voc is -0.27%/°C and of Isc is 0.04%/°C. This shows how the output changes as the panel gets hotter, which matters in Lahore’s summer heat.
